Horizontal Shaft Impact Crusher (HSI Impact Crusher)
PF Series Impact Crusher is a Horizontal Shaft Impact Crusher (HSI Crusher) designed for primary and secondary crushing applications. It is widely used for processing soft to medium-hard materials, including limestone, construction waste, concrete and various aggregate materials.
With a large crushing ratio, high impact efficiency and optimized crushing chamber design, PF Series Impact Crusher delivers excellent reduction performance and produces well-shaped cubic aggregates. It is an ideal choice for quarrying, aggregate production, construction material recycling and other crushing applications.
As a professional Impact Crusher manufacturer, Dahongli provides reliable PF Series Impact Crushers with durable wear parts, stable operation and flexible adjustment to meet different production requirements.
Working Principle
The impact crushers crush materials with high-speed impact. When materials enter the acting zone of the plate hammer through the feed port, they will be subject to high-speed impact of the hammer and crushed for the first time. The powerful impact force casts the materials to the impact plate, and the materials are crushed again. The materials sprung back from the impact plate fall upon the acting zone of the plate hammer. Then the above steps are repeated until the particle size of the crushed materials is smaller than the diameter of the discharge port. The crushed materials are subsequently discharged through the discharge port dependent upon their dead weight by adjusting the spacing between the impact bracket and the rotor, the particle size and shape of the discharged materials may be changed.
PF Series Hsi Crusher Machine Features
High Crushing Ratio
With high crushing ratio, simple and appropriate structure and high crushing efficiency, these crushers maintain steady operations and are easy to maintain.
It is expedient to replace the parts. Widely applied in sectors of building materials,mineral processing, chemical engineering and electric power, these crushers are mainly used for crushing materials with medium degree of hardness and britle materials.
Higher Production Efficiency
The optimized crushing chamber accepts materials with bigger feed particle size. The optimized liner and specific rotor greatly increase production efficiency under different conditions.
Durable And Reliable
The plate hammer, impact liner and wear parts inside the chamber are made of high chromium and manganese materials, which make wear parts (e.g.plate hammer and impact hammer)more durable and mechanical parts of the crusher (including spindie and bearings)more reliable.
Convenient Overhaul
The crusher may be configured for hydraulic uncovering,to make it convenient to disassemble and replace wear parts.
